PCB board handling equipment for automated assembly of PCB’s. ASCEN magazine PCB loader as SMT line auto PCB loader machine that feeds PCBs into the Process Line from Stacks or Magazines.

magazine PCB loader

magazine PCB loader Main Features:

1. Touch screen controlled component,easy to operate and convenient man-machine interaction.
2.Multiple sound and light alarming functions
3.Pneumatic PCB clamping structure
4. Lifting distance adjustable according to PCB, 4 kinds of distance(10mm, 20mm, 30mm and 40mm)
5.Loader configured with inner push board component, save the cost of buying PCB moving machine independently.
6. Optional SMEMA port for communication between machines.
7. Imported brake system locate accurately moving fast efficiently production.
8. Specific error checking system and security checking system is applied. Easy to handle with literal hint.
9. PLC system is adopted to provide stable performance.
10. SMEMA is adopted for connecting with other automatic equipment.
11. Imported ball screw and high carbon steel pillar is applied to generate less noise,less vibration and better positioning.
Please click the video link here PCB magazine loader ,  mini PCB loader to check the machine how to operate online.

ASCEN technology co.,ltd provide a full SMT assembly line solutions,including PCB magazine loader , PCB magazine unloader , PCB stacker , PCB turn coneyor PCB shuttle conveyor , PCB flip conveyor , PCB separator ,PCB depaneling machine , PCB cutting machine , PCB link conveyor , PCB turn conveyor , PCB buffer , PCB gate conveyor , vision measuring machine , PCB solder paste printer , full auto PCB screen printer , automatic optical inspection machine , PCB optical inspection machine ,  solder dross separator   are available as standard and customized products and can be equipped to fit special requirements

Please collecting our web:www.ascen.ltd  ,   we will updated more solution for help production line to save more cost.

Product Details:
1. touch screen controlling panel
PCB magazine loader machine

2. Inner structure

PCB magazine loader machine

3. Sending boards device
PCB magazine loader machine

PCB magazine loader machine technical parameters

Model NO. HY-250LD HY-330LD HY-390LD Customized large model for the bigger PCB board
PCB size(mm) (L*W)-(L*W) (50*50)-(350*250) (50*50)-(350*330) (50*50)-(350*390)
Machine Size(mm) (L*W*H) 1100*780*1200 1400*860*1200 1500*920*1200
Magazine Size (mm) (L*W*H) 355*320*565 460*400*565 535*460*565
Weight(kg) Approx. 140kg Approx.180kg Approx.220kg
